Weight
60.48lbs
Total Weight Limit
330 lbs
Ebike Class
Class 2 Ebike
Water Resistance
Bike - IPX5 // Components - IPX6
Range
Up to 75 Miles
Safety Certifications
UL Safety Certified UL 2849
Battery Safety Certifications
Certified to UL 2271
Rider Height
R: 5'0" - 5'9" | L: 5'9" - 6'3"
Speed
Max: 28 MPH
Saddle
Aventon 250mm wide Saddle
Seatpost
Aventon Seatpost, 30.9Ø, Length: 300 mm (Size R) / 350 mm (Size L)
Seatpost Clamp
34.9mm
Handlebars
Aventon aluminum swept back handlebars, 31.8mm, 620mm, 38mm rise
Stem
60mm length, Adjustable rise, 31.8 handlebar clamp
Grips
Aventon Lock on grips
Headset
Sealed Bearing Headset
Frame
6061 Aluminum, Gravity Cast Front Triangle
Fork
Aventon Rigid Alloy
Rear Spacing
147mm
Fork Spacing
100mm
Front Wheel
27.5" Double Wall Aluminum rim, 36 13g spokes, 15x100mm Thru Axle, Schrader Valve
Rear Wheel
27.5" Double Wall Aluminum rim, 36 12g spokes, 750W Nutted Axle Hub Motor, Schrader Valve
Tires
27.5x2.1 33TPI
Front Brake
Tektro HD-E3120 hydraulic disk
Rear Brake
Tektro HD-E3120 hydraulic disk
Front Brake Rotor
180mm 6 bolt
Rear Brake Rotor
180mm 6 bolt
Brakes
Regenerative Braking
Cassette
Shimano CS-HG200-8 8 speed Cassette, 12-32T
Rear Derailleur
Shimano Altus RD-M310 8 Speed
Shifter
Shimano 8 Speed Trigger SL-M315-8R
Chain
7/8 speed 122L
Chainring
48T
Crankset
3pc, 165mm crank arm
Bottom Bracket
Square Tapered, Sealed, Double Sided Torque Sensor, 83mm x 158.5mm
Pedals
9/16" Composite Platform
Motor
36V, 750W Hub Drive
Motor Torque
80Nm (96Nm in Boost Mode)
Motor Power
750W, 1188 Watt Peak (1440 watt peak in boost mode)
Display
Aventon A280
Battery
Removable Internal Lithium-ion, 36V, 20Ah, 733Wh, LG 21700 cells
Battery Weight
8.7lbs
Controller
36V, 33A
Throttle
Aventon LH Handlebar Mounted
Sensors
Double Sided Bottom Bracket Torque Sensor
Charger
36V Output: 42V/ 4A
Charging Time
5 hours
Lights
Front and rear lights integrated
ACU Over-The-Air Updates
Yes
Smart Features
Regenerative Braking, Ride Tune, 4G/GPS, Unusual activity detection, E-lock, Hold Mode, Remote Notification, Apple Watch Connectivity, Keyless Battery, Cruise Control, Boost Mode, Sensor Switch
